规格 |
Umin |
Umax |
应用 |
保护脚 |
最大容通电流 |
动作时间 |
电容 |
|
RJ11S-V24T/4-F |
12V |
18V |
RS-232(V.24)O.H.
Token Ring |
Pin2,3,4,5 |
340A |
<10ns |
<40pF |
|
RJ11S-V11EI/4-F |
6V |
7.5V |
RS-422/485(V.11)
Ethermet 10 base T |
Pin2,3,4,5 |
750A |
<10ns |
<40pF |
|
RJ11S-Tele/2-F |
110V |
240V |
Moden/fax
Telecommunication |
Pin3,4 |
250A |
<10ns |
<40pF |
|
RJ11S-Tele/4-F |
110V |
240V |
Moden/fax
Telecommunication |
Pin2,3,4,5 |
1.5kA |
<10ns |
<o.5dB |
|
RJ11S-Tele/6-F |
110V |
240V |
Moden/fax
Telecommunication |
Pin1-6 |
250A |
<10ns |
<40pF |
|
RJ45S-V24T/4-F |
12V |
18V |
RS-232(V.24)O.H.
Token Ring |
Pin3,4,5,6 |
340A |
<10ns |
<40pF |
|
RJ45S-V24T/8-F |
12V |
18V |
RS-232(V.24)O.H.
Token Ring |
Pin1-8 |
340A |
<10ns |
<40pF |
|
RJ45S-E100/4-F |
6V |
7.5V |
Ethermet 10/100 Base T
(twisted pair) |
Pin1,2,3,6 |
750A |
<10ns |
<40pF |
|
RJ45S-V11I/4-F |
6V |
7.5V |
RS-422/485(V.11) |
Pin3,4,5,6 |
750A |
<10ns |
<40pF |
|
RJ45S-V11EI/8-F |
6V |
7.5V |
RS-422/485(V.11)
Ethermet 10 base T |
Pin1-8 |
750A |
<10ns |
<40pF |
|
RJ45S-Tele/4-F |
110V |
240V |
Moden/fax
Telecommunication |
Pin3,4,5,6 |
1.5kA |
<10ns |
<o.5dB |
|
RJ45S-Tele/8-F |
110V |
240V |
Moden/fax
Telecommunication |
Pin1-8 |
250A |
<10ns |
<40pF | |
